JINHENG focuses on the research and development and production of ultra-high performance concrete mixers, with vertical axis planetary mixers applied in the ultra-high performance concrete industry. Single motor drive, stable operation, quickly dispersing fibers to uniformity; Durable, efficient, and easy to maintain;
The improvement of tensile strength and toughness in ultra-high performance concrete mainly relies on the addition of steel fibers, which requires the material to ensure that steel fibers can be evenly distributed in cement-based materials during the preparation process.
JINHENG ultra-high performance concrete mixer is a specialized mixer designed and developed for the production of ultra-high performance concrete, based on the technology of vertical axis planetary mixer and combined with the actual production conditions in the industry.
| Type | Dry filling | Production of each batch of hard concrete | Mixing star wheel and blades | Drive power | Maximum granularity | |
|---|---|---|---|---|---|---|
| Mixing | Hydraulic unit | High quality concrete | ||||
| UHPC330 | 500L | 330L | 1x2 | 22/30 KW | 2.2KW | 70mm |
|
UHPC500 |
750L | 500L | 1x2 | 30/37 KW | 2.2 KW | 70 mm |
| UHPC750 | 1125L | 750L | 1x3 | 37/45 KW | 2.2 KW | 70 mm |
| UHPC1000 | 1500L | 1000L | 2x2 | 45/55 KW | 2.2 KW | 70 mm |
| UHPC1500 | 2250L | 1500L | 2x2 | 55/75 KW | 2.2 KW | 70 mm |
| UHPC2000 | 3000L | 2000L | 3x2 | 75/90 KW | 3 KW | 70 mm |
