Screw conveyors

Screw conveyors are mainly used for conveying powders, particles, and small materials with certain fluidity. Our spiral machine is currently widely used in concrete mixing plants, asphalt mixing plants, feed, chemical and other industries; It can be used for transporting various materials such as cement, fly ash, mineral powder, sand, ice, etc. Product features: Made of high-quality steel pipes, with good overall rigidity. Double pitch blades can reduce the degree of compression during material transportation. Adopting high-quality gearbox, heavy-duty design, with high torque, low noise and other characteristics. Optional universal joint for easy installation and adjustment of the steering device. Equipped with high-quality suspension bearings and tail bearings, easy to install.

Details

Technical Parameter

Diameter	Ф168	Ф219	Ф273	Ф323	Ф407
Conveying rate	24t/h	40t/h	80t/h	110t/h h	170t/h
	1500-5-28-4	1500-5-28-4	2000-7-38-5.5	2000-7-38-7.5	3000-10-42-15
	1500-5-28-4	1500-5-28-4	2000-7-38-5.5	2000-7-38-7.5	3000-10-42-15
	1500-5-28-4	1500-5-38-5.5	2000-7-38-7.5	2000-7-42-11	3000-10-42-15
	1500-5-28-4	1500-5-38-5.5	2000-7-38-7.5	2000-7-42-11	3000-10-42-15
	1500-5-38-5.5	1500-5-38-7.5	2000-7-42-11	3000-10-42-15	3000-10-48-18.5
	1500-5-38-5.5	1500-5-38-7.5	2000-7-42-11	3000-10-48-18.5	3000-10-48-18.5
	1500-5-38-7.5	1500-5-42-11	2000-7-42-15	3000-10-48-18.5	3000-10-48-22
	1500-5-38-7.5	1500-5-42-11	2000-7-42-15	3000-10-48-22	3000-10-48-22
	1500-5-38-7.5	1500-5-42-11	2000-7-42-15	3000-10-48-22	3000-10-60-37
	1500-5-38-7.5	1500-5-42-11	3000-7-42-15	3000-10-48-22	3000-10-60-37
	1500-5-38-7.5	1500-5-42-11	3000-7-48-18.5	3000-10-48-22	3000-10-60-37
	1500-5-38-7.5	1500-5-42-15	3000-7-48-18.5	3000-10-48-30	3000-10-60-37
	1500-5-38-7.5	1500-5-42-15	3000-7-48-18.5	3000-10-48-30
		1500-5-42-15	3000-7-48-18.5	3000-10-48-30

Highlights

Using high-quality steel pipes, the overall rigidity is good.
Double pitch blades can reduce the degree of compression during material transportation.
Adopting high-quality gearbox, heavy-duty design, with high torque, low noise and other characteristics.
Optional universal ball joint for easy installation and adjustment of the steering device.
Equipped with high-quality suspension bearings and tail bearings, easy to install.
Adequate spare parts with complete specifications.
Commonly used diameters of 114, 168, 219, 273, 323, and 407 are all in stock and can be customized in size and angle according to customer requirements.
Standard component assembly for easy transportation.
Equipped with optional high temperature and room temperature configurations.
